Aircraft Detail Design Manual - PDF eBook

Aircraft Detail Design Manual - PDF eBook


$18.95
SKU 0633-JPG-Egray stars
Which product format is best for you?
Qty

Product Features

  • ISBN: 0877940115
  • Edition: 3rd
  • Pages: 99
  • Look Inside: View
  • eBook Specifications

    • Type: Unsecure eBook (PDF)
    • Printing: Yes; Unlimited
    • Copy/Paste: Unlimited
    • Offline Access: Yes
    • Search: Yes
    • Bookmarks: Yes
    • Compatibility: Windows, macOS, iOS, Android
This is a large format book giving detailed scaled drawings of various light aircraft components such as control surface hinge assemblies, tail wheel mounts, strut fittings, engine mounts, axles, control linkages and many others. The intention is not that you would copy or build these exact components (although the drawings are sufficient to do so), but instead that you can see and study the standards of how such components are designed and built, so that you can apply those standards when designing for your own specific needs. Additional sections include practical wing design, and conversion and engineering tables to assist in your specific design applications.

How To Get And Use Your Unsecure eBook

An Unsecured eBook is a standard PDF viewable by any PDF reader application. In the event you don't have a default PDF reader, visit https://get.adobe.com/reader to get a FREE PDF reader. Unsecured PDFs have no restrictions and may be used on any device that supports PDFs.
