Electrical Wiring 101 - eVideo

Electrical Wiring 101 - eVideo


$25.00
SKU 0721-HBH-EVgray stars
Which product format is best for you?
Qty

Product Features

  • Publisher: Homebuilt Help
  • Time: 82

This eVideo is a beginner's guide to electrical wiring for simple to mid-performance homebuilt aircraft.

It demonstrates the basic tools, components, procedures, and choices involved in designing and wiring a basic panel and electrical system. For those building or working with more complex aircraft, this is the place to start. Once you've mastered these skills, you will be ready for the more involved installations.

Topics Include:

  • Selecting the proper wire size and type.
  • Stripping wires - splicing wire - selecting fuses.
  • Crimping connectors - soldering large connectors.
  • Use of heat shrink.
  • Routing wire bundle.
  • Main and ground electrical buss.
  • Aircraft batteries - wiring a starter solenoid.
  • Wiring an ammeter shunt.
  • Planning and building your panel.
  • Drawing simple schematics.
  • Simple circuit designs.
  • Troubleshooting circuits with a multi meters.
